Clevite Cb-1663H-10 Coated H-Series Connecting Rod Bearings – Oversize Option

Description

Brand: Clevite Engine Parts
Manufacturer’s Part Number: CB-1663H-10
Part Type: Rod Bearings
Product Line: Clevite Coated H-Series Rod Bearings
Automotive Fittings Part Number: CLE-CB1663H10
UPC: 27067083319
Bearing Usage: Performance
Engine Crankshaft Undersize (in.): 0.010 in.
Engine Crankshaft Undersize (mm): 0.25mm
Bearing Material: Tri-metal, TM-77
Dowel Pin Hole: No
Narrow Bearing: Yes
Quantity: Sold individually.
Notes: Triarmor coated.
Description:
Clevite coated H-Series rod bearings were developed primarily for NASCAR racing, but are also well suited to other types of competition engines. They’re especially good for engines that run at medium-to-high revs. They have hardened-steel backings with thin overlays and a high crush factor, plus a medium level of eccentricity. H-Series bearings feature Clevite’s exclusive TriArmor coating, the industry’s only moly/graphite treatment. The sophisticated blend, in a low-friction PTFE polymer base, offers extraordinary protection and lubricity. They also have enlarged chamfers at the sides for greater crank-fillet clearance and are made without flash plating for better seating. The Clevite coated H-Series rod bearings are available with various under-sizes, including 0.001 in. of clearance for polished journals.
